FNCP 50B Series Programmable Encoder

Features

  • Industry 50 mm standard size
  • Clamping clamping flange
  • Robust mechanical and electrical construction
  • Protection up to IP67
  • Up to 65.536 PPR max.
  • <2 MHz frequency
  • Programming via FNC PT - PT programming tool
  • FNC PT-PS easy programming software


ISBN : FNCP 50B 10630VX - R2


Flange Diameter 50 mm,
Supply Voltage 5V : 5V in/out, 30V : 5-30V in/out,
Connection Type 1 mt Cable, 2 mt Cable, 5 mt Cable, 7 mt Cable, 10 mt Cable, M12/4pin, M12/5pin, M16/7pin, M16/14pin, M23/12pin,
Shaft Diameter 4 mm, 6 mm, 8 mm, 10 mm, 12 mm, 14 mm,
Resolution / Pulse 10, 16, 25, 30, 40, 50, 60, 88, 90, 100, 141, 200, 250, 300, 360, 400, 500, 512, 600, 625, 800, 900, 1000, 1024, 1200, 1250, 1440, 2000, 2048, 2500, 3000, 3600, 4000, 4096, 5000, 6000, 8000, 8192, 10000, 12500, 16384, 20000, 25000, 65536,
Output Circuit / Push-Pull ABZ:3, AB+A'B:4, ABZ + A'B'Z':6,
Product Group Programmable Rotary Encoders,
