SSI + BISS Motor Feedback Encoders

• Absolute encoder with parallel interface
• Magnetic sensing
• Resolution: up to 12 bit
• Synchro or clamping flange
• Optional preset input
• Optional direction input

• Industry 58 mm standard size, clamping flange
• Robust mechanical and electrical construction
• Protection to IP67
• Up to 25.000 PPR max.
• <300 k Hz frequency

• Programmable measuring range
• Industry 58 mm hollow shaft version
• Robust mechanical and electrical construction
• Protection up to IP67
• 0-10V voltage / 4-20 mA current output

• Encoder single - or multiturn / SSI - BISS
• Magnetic Sensing
• Magnetic single turn resolution: 9 ... 14 bit
• Multi-turn 0...32 bit
• Clamping flange or synchro flange
• Permanent check of code continuity
• Extreme resistance to shock and vibration
• Encoder with electronic reset

Industry 50 mm size, 20 mm diameter clamping flange
Compatible with universal 40 mm encoders
Robust Mechanical and Electrical Construction
Protection up to IP67
Up to 5000 PPR max.
<300 kHz frequency

• Industry 50 mm Standard Size, through  hollow shaft
• Robust Mechanical and Electrical Construction
• Protection up to IP67
• Up to 5000 PPR max.
• <300 kHz frequency
• Double-Sided Bearings

• Digital Tachogenarator with robust tacho flange
• Industry 115 mm standard size
• High noise immunity against frequency inverters
• Protection up to IP67
• Up to 5.000 PPR max.
• <300 kHz frequency

• Resolution up to 0,001 mm
• Robust mechanical and electrical construction
• Protection to IP67
• Periodic reference signal
• Magnetic FMTL500 (Linear), FMTR500(Rotary)
• Magnetic FMTL200 (Linear), FMTR200(Rotary)

• Industry 58 mm Standart Size, Clamping Flange
• Robust Mechanical and Electrical Construction
• Protection up to IP67
• Up to 25.000 PPR max.
• <300 kHz Frequency

• Industry 50 mm Standart Size, Clamping Flange
• Robust Mechanical and Electrical Construction
• Protection up to IP67
• Up to 5000 PPR max.
• <300 kHz frequency

• Industry 30 mm special size, servo flange, and clamp flange
• Robust mechanical and electrical construction
• Protection up to IP57
• Up to 2500 PPR max.
• <300 kHz frequency

• Encoder single or multiturn / bus cover
• Magnetic sensing
• Single turn resolution: 12...19 bit
• Multi-turn 4...32 bit
• End hollow shaft
• Permanent check of code continuity
• Extreme resistance to shock and vibration
• Modular Fieldbus interfaces
• Profibus / CANopen

• Industry 50 mm Stand Size, Clamping Flange
• Robust Mechanical and Electrical Construction
• Protection up to IP67
• Up to 5000 PPR max.
• <300 kHz Frequency

• Industry 40 mm, end or through hollow shaft
• Robust mechanical and electrical construction
• Protection up to IP67
• Up to 5000 PPR max.
• 2P, 3P, 4P, 5P pole pairs options
