PRODUCT DETAILS
FNC F82P Series Encoder
Review the specifications and find a solution for your application.
Stock code: FNC F82p 44630V1024 - R7
FNC F82P Series Encoder
- Special 80 mm Design, Through Hollow Shaft
- Robust Mechanical and Electrical Construction
- Protection up to IP67
- Up to 8192 PPR max.
- <300 kHz Frequency
General Features
- Special 80 mm Design, Through Hollow Shaft
- Robust Mechanical and Electrical Construction
- Protection up to IP67
- Up to 8192 PPR max.
- <300 kHz Frequency
| Product Group | Incremental Rotary Encoders |
|---|---|
| Flange Diameter | 80 mm |
| Shaft Diameter | 25 mm, 28 mm, 30 mm, 35 mm, 32 mm, 38 mm, 40 mm, 42 mm, 44 mm |
| Output Circuit / Push-Pull | A:1, AB:2, ABZ:3, AB+A'B:4, ABZ + A'B'Z':6 |
| Resolution / Pulse | 1024, 2000, 2048, 4000, 4096, 8000, 8192 |
| Connection Type | 1 mt Cable, 2 mt Cable, 5 mt Cable, 7 mt Cable, 10 mt Cable, M12/4pin, M12/5pin, M16/14pin, M23/12pin |
| Supply Voltage | 5V : 5V in/out, 30V : 5-30V in/out, 10 - 30VDC |
