SSI + BISS Motor Feedback Enkoderler

• Robust, compact housing
• Two bearings with large distance
• High shaft load up to 400 N
• Highest operating speed 10000 rpm
• Terminal box, 23 connector, Cable options

• Measurement length up to 10000 mm
• Robust aluminum housing
• Very compact design
• Protection to IP54
• Wire actuated encoder for all rotary encoders with 58 mm servo flange and different signal outputs
• Stainless steel wire

• Suitable for measuring the length and speed of the moving target by selecting wheel type
• Successively by wheel type is suitable for measuring the length or speed of the moving target
• Distance measurement output wavelength and it conforms to the international measurment
• Different wheel diameters and surface options depending on the application
• Protection up to IP65 or IP54
• Easy Mounting
• <300  kHz frequency

• Industry 58 mm standard size, clamping flange
• Robust mechanical and electrical construction
• Protection to IP67
• Up to 25.000 PPR max.
• <300 k Hz frequency

50 mm boyutlarında, 20mm çap sıkma flanş
Evrensel 40 mm kodlayıcı ile uyumlu
Sağlam Mekanik ve Elektrik İnşaat
IP67 koruma
5000 PPR ma.
<300 kHz frekansı
Gerilim Suplly: 4.75VDC için 30VDC - 4.75VDC için 5.5VDC
Ölçüleri (Flanş): Ø50 mm
Ağırlık Yaklaşık: 200 gr

• Encoder single or multiturn / bus cover Magnetic sensing Single turn resolution: 12...19 bit Multi-turn 4...32 bit End hollow shaft Permanent check of code continuity Extreme resistance to shock and vibration Modular Fieldbus interfaces Profibus / CANopenEncoder single or multiturn / bus cover
• Magnetic sensing
• Single turn resolution: 12...19 bit
• Multi-turn 4...32 bit
• End hollow shaft
• Permanent check of code continuity
• Extreme resistance to shock and vibration
• Modular Fieldbus interfaces
• Profibus / CANopen

• Industry 58 mm standard size, clamping flange
• Robust mechanical and electrical construction
• Protection to IP67
• Up to 65.536 PPR incremental output
• <1 MHz frequency
• Up to 10-bit parallel output
• Optional strobe output for parallel output
• Optional direction change input

• Gövde çapı 64mm
• Flanş gövde
• Yüksek Çözünürlülük
• Farklı Çalışma voltajları
• ABN ve ABN inv. kare dalga çıkışlı
• Çalışma frekansı 200kHz
• Push-pull
• Koruma sınıfı IP67, şaftta IP65
• Sağlam Kompakt Tasarım
• 2 yıl garanti

• Resolution up to 0,001 mm
• Robust mechanical and electrical construction
• Protection to IP67
• Periodic reference signal
• Magnetic FMTL500 (Linear), FMTR500(Rotary)
• Magnetic FMTL200 (Linear), FMTR200(Rotary)

• Absolute encoder with parallel interface
• Magnetic sensing
• Resolution: up to 12 bit
• Synchro or clamping flange
• Optional preset input
• Optional direction input

• Gövde Çapı 80mm
• Delil Çapı 8,10,12,14mm
• ÇÖzünürlülük 1....5.000puls
• ABN ve ABN ters kare dalga çıkışlı
• SIN/COS Çıkış
• Çalışma Frekansı 200kHz
• Push-Pull
• Çalışma Sıcaklığı -20+80 C

• Encoder single - or multiturn / SSI - BISS
• Magnetic Sensing (Optional optical sensing)
• Optical single turn resolution: 12 ... 19 bit
• Magnetic single turn resolution: 9 ... 13 bit
• Multi-turn 4...32 bit
• Clamping flange or synchro flange
• Permanent check of code continuity
• Extreme resistance to shock and vibration
• Encoder with electronic reset

• Gövde çapı 30mm
• Flanş gövde
• Yüksek Çözünürlülük
• Farklı Çalışma voltajları
• ABN ve ABN inv. kare dalga çıkışlı
• Çalışma frekansı 200kHz
• Push-pull
• Koruma sınıfı IP67, şaftta IP65
• Sağlam Kompakt Tasarım
• 2 yıl garanti
