PRODUCT DETAILS
FNC 100H Series Encoder
Review the specifications and find a solution for your application.
Stock code: FNC 100H 38630V1024 - R2
FNC 100H Series Encoder
- Industry 100 mm design, through hollow shaft
- Robust mechanical and electrical construction
- Protection up to IP67
- Up to 10.000 PPRmax.
- <300 kHz frequency
General Features
- Industry 100 mm design, through hollow shaft
- Robust mechanical and electrical construction
- Protection up to IP67
- Up to 10.000 PPRmax.
- <300 kHz frequency
| Product Group | Incremental Rotary Encoders |
|---|---|
| Flange Diameter | 100 mm |
| Shaft Diameter | 26 mm, 28 mm, 30 mm, 32 mm, 38 mm, 40 mm, 42 mm, 44 mm |
| Output Circuit / Push-Pull | A:1, AB:2, ABZ:3, AB+A'B:4, ABZ + A'B'Z':6 |
| Resolution / Pulse | 1024, 2000, 2048, 2500, 4000, 4096, 5000, 8000, 8192, 10000 |
| Connection Type | 1 mt Cable, 2 mt Cable, 5 mt Cable, 7 mt Cable, 10 mt Cable, M12/4pin, M12/5pin, M16/7pin, M16/14pin, M23/12pin |
| Supply Voltage | 5V : 5V in/out, 30V : 5-30V in/out, 10 - 30VDC |
